HIKVISION DS-K2802 Quick Start Guide

DS-K2800 Serial Access Controller
9
No.
DS-K2802
A3
IN1
Alarm Input 1
B1
Door 2
NC
Door Lock Relay Output (Dry Contact)
B2
COM
B3
NO
B4
BUTTON
Door Button Input
B5
GND
Grounding
B6
SENSOR
Door Magnetic detector
B7
Door 1
NC
Door Lock Relay Output (Dry Contact)
B8
COM
B9
NO
B10
BUTTON
Door Button Input
B11
GND
Grounding
B12
SENSOR
Door Magnetic detector
D1
Power
GND
DC12V Grounding
D2
+12V
DC12V Input
E1
Alarm Output 2
COM2
Alarm Relay Output 2 (Dry Contact)
E2
NO/NC2
E3
Alarm Output 1
COM1
Alarm Relay Output 1 (Dry Contact)
E4
NO/NC1
C1
Wiegand Card Reader 1
OK
Indicator of Card Reader Control
Output (Valid Card Output)
C2
ERR
Indicator of Card Reader Control
Output (Invalid Card Output)
C3
BZ
Card Reader Buzzer Control Output
C4
W1
Wiegand Head Read Data Input Data1
C5
W0
Wiegand Head Read Data Input Data0
C6
PWR
Card Reader Power Output
C7
GND
C8
Wiegand Card Reader 2
OK
Indicator of Card Reader Control

HIKVISION DS-K2802 Specifications

General

Product type	Access controller
Certification	CE, FCC
Compatibility	Wiegand
Mounting type	Wall
Product color	Black
Brand compatibility	Hikvision
Operating temperature (T-T)	-20 - 65 °C
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	285 mm
Width	237 mm
Height	69 mm
