HIKVISION DS-K2802 Quick Start Guide

DS-K2800 Serial Access Controller
12
No.
DS-K2804
A7
Door 4
NC
Door Lock Relay Output (Dry Contact)
A8
COM
A9
NO
A10
BUTTON
Door Button Input
A11
GND
Grounding
A12
SENSOR
Door Magnetic detector
A13
Door 3
NC
Door Lock Relay Output (Dry Contact)
A14
COM
A15
NO
A16
BUTTON
Door Button Input
A17
GND
Grounding
A18
SENSOR
Door Magnetic detector
A19
Door 2
NC
Door Lock Relay Output (Dry Contact)
A20
COM
A21
NO
A22
BUTTON
Door Button Input
A23
GND
Grounding
A24
SENSOR
Door Magnetic detector
A25
Door 1
NC
Door Lock Relay Output (Dry Contact)
A26
COM
A27
NO
A28
BUTTON
Door Button Input
A29
GND
Grounding
A30
SENSOR
Door Magnetic detector
B1
Wiegand Card Reader 1
OK
Indicator of Card Reader Control
Output (Valid Card Output)
B2
ERR
Indicator of Card Reader Control
Output (Invalid Card Output)
B3
BZ
Card Reader Buzzer Control Output

HIKVISION DS-K2802 Specifications

General

Product type	Access controller
Certification	CE, FCC
Compatibility	Wiegand
Mounting type	Wall
Product color	Black
Brand compatibility	Hikvision
Operating temperature (T-T)	-20 - 65 °C
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	285 mm
Width	237 mm
Height	69 mm
