HIKVISION DS-U04P - 2.1 Angle Adjustment; 2.2 Mounting Methods; 2.2.1 Place on the Desktop; 2.2.2 Clamp on the Display

2.1 Angle Adjustment
The device can be adjusted as shown in Figure 2-1.
-15°~15°
0°~180°
15°15°
360° Horizontal Rotation
Figure 2-1 Angle Adjustment
2.2 Mounting Methods
2.2.1 Place on the Desktop
You can place the device on the desktop in the
following way.
Figure 2-2 Place the Device on the Desktop
2.2.2 Clamp on the Display
You can clamp the device on the display of different
thickness.
Figure 2-3 Clamp the Device on the Display
2.2.3 Install to the Bracket
You can also install the device to bracket through
1/4-20UNC-2B screw hole.
