1 Introduction
1.1 Product Features
Key features of the device include:
 High-performance CMOS
 Sharp and high-quality images
 AGC for self-adaptive brightness
 Built-in microphone with clear sound
 USB interface. Plug-and-play, no need to install driver
software
Figure 1-1 Connection
1.2 Overview
6
1
2
3
4
5
2
Figure 1-2 Appearance
Table 1-1 Description
No.
Description
No.
Description
1
Main Body
4
Bracket
2
Microphone
5
USB Power Cable
3
Lens
6
Indicator
Notes:
 The indicator in red means the device is standing by.
The indicator in blue means the device is on video
call.
 Devices with different lens may differ from the image.
Take the actual object as standard.
 Peel off the protective film before use.
