HIKVISION Ultra Series Quick Start Guide

Network Box Camera·Quick Start Guide
12
Rear Panel Interface Description
Item
Description
Item
Description
VIDEO
OUT/CVBS
Analog video
output interface
RS-485
D+ or D- connect
to 485
AUDIO IN
Audio input
interface
AUDIO
OUT
Audio output
interface
ALARM IN
Alarm input
interface,
IN1 and GND1,
IN2 and GND2
are two pairs of
alarm inputs
ALARM
OUT
Alarm output
interface,
1A and 1B, 2A and
2B, 3A and 3B are
three pairs of
alarm outputs
SFP
Optical interface
LAN(PoE)
Network interface,
PoE supported
RESET
One-key reset
button
ABF
Auto back focus
adjusting knob
DC 12V, AC
24V
Power input
DC12V,
GND
/DC
12V_OUT
Power output
interface
Grounding
MicroSD
SD
Memory card slot
Insert the memory
card for local
storage
