Likorall™
Cable for Hand control with Connecting Plug LR24
Manöverkabel med kontakt LR24
Assembly Instruction
Monteringsanvisning
Prod. No. 31290014
3SE640221-01
2013-02-27
© Copyright Liko AB
www.liko.com
Tools required:
5.94
NOTE
- Make sure the spare part is mounted according to the assembly instruction.
- Check all functions related to the changed spare part.
- Repairs and maintenance may only be performed by personnel authorized by Hill-Rom/Liko and using original Liko spare parts.
Contains: Qty:
Cable for hand control, 5 pol 1
Fits: Prod. No.
HandControl LR 2 buttons 3126031
(Likorall 240/240 R2R )
Prod. No. 3126031
Liko AB, Nedre vägen 100, 97592 Luleå, Sweden
Y/M: 20XX-XX
IP 43
234XXXXXX
- yellow white brown green grey - -
Old version of Handcontrol
- red blue grey white green brown yellow
