hilmor 1950217 - Screen & Button Layouts

1-800-628-8810
7
1/4" Female-to-Female
Adapter
check sensor
Pa kPa mTorr Torr mmHG micron
alarm
moisture
low point high point
units/min
.8.8.8.8.8.8
.0.0.0.8
.8.8.8. 8.8.8.8
check sensor
units/min
.0.0.0.8
alarm
moisture
Sync /
Signal Strength
Check Sensor –
Connection Lost
Battery Level
Pressure Reading
Units of Vacuum
Rate of Change
Alarm ON
Moisture Detected
Alarm Set Value - Low
Alarm Set Value - High
Vacuum
Progress Bar
SCREEN & BUTTON
LAYOUTS
SCREEN ICONS
Scroll Up
Scroll Down
BUTTONS
Power/Backlight Button
Function Button
