Hiniker 6000 - Prince 5 Inch Diameter X 16 Inch Stroke Cylinder 7;8 O-Ring Ports

Page 6
SERIES 6000 ROW CULTIVATOR
11/10
18
17
4
2
7
15
10
11
12
13
6
9
1
3
14
16
5
8
19
20
S
E
C
3
PRINCE 5 INCH DIAMETER X 16 INCH STROKE CYLINDER 7/8 O-RING PORTS
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1
2
3
4
5
6
7
8
9
10
11
12
840-001-189
81002593
840-001-191
81002592
81002591
840-001-194
951-005-034
855-001-424
81002590
Piston Rod
#10 SAE Plug
Tube
Butt
Gland
Piston
Uni-Torque Lock Nut 1 1/4 -12
Hex Nut
Tie Rod
O-Ring
O-Ring
BU-Washer
1
1
1
1
1
1
1
4
4
2
1
2
13
14
15
16
17
18
19
20
81004348
840-001-206
81002585
81002594
81002581
81004351
O-Ring
U-Cup Seal
BU-Washer
Wiper
Clevis Pin
Hairpin Klip
Clevis Assembly
Seal Kit (Includes Items 10, 11, 12, 13, 14, 15 & 16)
Complete 5 x 16 Cylinder Assembly 1999 & Earlier
*Note: Items Marked “*” Are Available In Seal Kit
Bushing
1
1
2
1
1
2
1
2
DWG. NO. 2935
Cylinder Identification Hiniker P/N 81002581 1999 & Earlier
Prince P/N SAE9516
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1
2
3
4
5
6
7
8
9
10
81004885
840-001-191
81004884
81004873
81004874
81004875
81002585
85003501
81004878
840-001-206
Piston Rod
Tube
Tie Rod
Butt
Gland
Piston
Clevis
Lock Nut 1 1/2-12
Clevis Pin
Hair Pin Clip
1
1
4
1
1
1
1
1
1
2
11
12
13
14
15
17
18
81002593
*
*
*
*
*
*
81004876
81004872
Port Plug 7/8-14
Crown Seal
O-Ring
O-Ring
Bu Washer
Wiper
Bearing Ring
Seal Kit (Includes Items (12, 13, 14, 15, 16, 17 & 18)
Complete 5 x 16 Cylinder Assembly 2000 &
Later
3
1
2
1
2
1
1
5 x 16 Cylinder
DWG. NO. 6186
Prince P/N 35016SP
