Hiniker 6000 - Texas Hydraulic 3 Inch Diameter X 8 Inch Stroke Cylinder 3;4 O-Ring Ports

Page 7
SERIES 6000 ROW CULTIVATOR
11/10
S
E
C
3
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
5
TEXAS HYDRAULIC 3 INCH DIAMETER X 8 INCH STROKE
CYLINDER 3/4 O-RING PORTS
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1
2
3
4
5
6
7
8
9
10
11
12
80503852
80503851
80503850
80503849
80503847
80503846
80503845
80503844
80503831
80503843
80503842
80503841
Rod
Tube
Head
Base Clevis
Clip Pin
Clevis
Nut
Cap Screw
O-Ring
Clevis Pin
Clevis Pin
Locknut
1
1
1
1
4
1
1
1
1
1
1
1
13
14
15
16
17
18
19
20
21
22
80503840
80503839
80503838
80503837
80503836
80503835
80503834
80503833
80503832
80503848
80503853
80503830
Plug
Nut
Lock Nut
Tie Rod
Wiper
Uni-Ring
U-Cup
Back-Up Washer
O-Ring
Piston
Seal Kit Includes Item 9, 17, 18, 19, 20 & 21
Complete 3 x 8 Cylinder
1
4
4
4
1
1
1
2
2
1
DWG. NO. 2305
Texas Hydraulic P/N CHA3022E080-04
