Hiniker 6000 - NH3 Coil Shank and Bracket Assembly; NH3 Disc Closer Assembly

Page 3
SERIES 6000 ROW CULTIVATOR
11/10
S
E
C
5
3
4
1
3
3
9
2
7
5
8
2
6
NH3 COIL SHANK AND BRACKET ASSEMBLY
DWG. NO. 2881
2
3
4
5
6
1
1
NH3 DISC CLOSER ASSEMBLY
DWG. NO. 2876
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1
2
3
4
81004122
81004132
953-003-003
950-001-293
Disc Assembly
Cable Tube Weldment
Spring Pin
Hex Hed Cap Screw 1/2-13 x 2 1/2 Gr. 8
2
1
2
1
5
6
951-001-007
952-001-004
81004120
Hex Nut 1/2-13
Lock Washer 1/2 Inch
Complete Anhydrous Disc Closer Assembly
1
1
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1
2
3
4
5
950-001-284
950-001-159
10304
951-005-044
950-001-147
Hex Head Cap Screw 1/2-13 x 4 3/4 Gr. 5
Hex Head Cap Screw 1/2-13 x 2 1/2 Gr. 5
2-Way Lock Nut 1/2-13
2-Way Lock Nut 5/8-11
Hex Head Cap Screw 5/8-11 x 2 1/2 Gr. 5
2
8
8
1
1
6
7
8
9
81004490
81004228
81004489
81004108
81004113
Saddle Bracket Weldment
Side Plate
Top Plate
Coil Shank
Complete Coil Shank W/Mount Bracket (1 Row)
1
2
1
1
