Hiniker 6000 - Coulter Scraper; Liquid Fertilizer Tube

Page 4
SERIES 6000 ROW CULTIVATOR
11/10
S
E
C
5
1
3
4
2
5
7
7
5
5
6
6
5
7
6
6
Serial No. Ending 101 Or Higher
Serial No. Ending 100
COULTER SCRAPER
DWG. NO. 2882
2
1
Serial No. Ending 101 Or Higher
Serial No. Ending 100
LIQUID FERTILIZER TUBE
DWG. NO. 2877
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1 81004446 Fertilizer Tube Weldment With Instruction
Sheet
1 2 81004119 Liquid Fertilizer Tube Assembly With
Instruction Sheet
1
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1
2
3
4
81004114
81004115
950-006-002
951-005-064
Flat Spring
Rotary Scraper
Hex Head Shoulder Bolt 5/16-18 x 5/8
2-Way Lock Nut 5/16-18
2
2
2
2
5
6
7
951-005-003
950-003-024
81004121
81004118
Lock Nut 3/8-16
Carriage Bolt 3/8-16 x 3/4 Gr. 5
Rotary Scraper Assembly
Complete Rotary Scraper Assembly (1 Row)
4
4
2
