Page 11
SERIES 6000 ROW CULTIVATOR
11/10
S
E
C
5
TELESCOPING REAR HITCH
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1
2
3
4
5
6
7
8
9
10
11
12
81004163
810-002-212
81004153
81004161
81004136
810-001-522
810-001-551
810-001-526
810-001-527
952-002-010
953-003-003
875-001-038
Hitch Weldment
Support Weldment
Mount Strap Weldment
Hitch Plate Weldment
Decal
Handle Weldment
Shield Mount Strap (Used With Rotary Hoe
Wheel And Rolling Shields)
Collar
Spring
Flat Washer 1 Inch
Spring Pin 1/4 x 1 3/4
U-Bolt
1
2
2
1
2
1
4
4
1
1
1
13
14
15
16
17
18
19
20
21
22
23
24
952-001-005
951-001-008
952-001-008
951-001-010
952-001-006
951-001-009
950-001-147
950-001-168
950-001-141
950-003-021
81004690
950-001-210
81004116
Lock Washer 5/8 Inch
Hex Nut 5/8-11
Lock Washer 7/8 Inch
Hex Nut 7/8-9
Lock Washer 3/4 inch
Hex Nut 3/4-10
Hex Head Cap Screw 5/8-11 x 2 1/2 Gr. 5
Hex Head Cap Screw 7/8-9 x 3 Gr. 5
Hex Head Cap Screw 5/8-11 x 3 Gr. 5
Carriage Bolt 5/8-11 x 1 1/4 Gr. 2
Lock Plate
Hex Head Cap Screw 7/8-9 x 10 Gr. 5
Complete Hitch Assembly
2
14
14
8
8
4
4
8
2
8
2
8
DWG. NO. 2862
