Hiniker 6000 - Rigid Toolbar Mounting Rolling Shield and Rotary Hoe Wheel

Page 12
SERIES 6000 ROW CULTIVATOR
11/10
S
E
C
5
30"
2 7/8"
TYP.
7
2
3
4
5
1
6
5
4
WELD SHIELD MOUNT
STRAP (ITEM 7) TO
HITCH SUPPORT (ITEM 6)
TELESCOPING
REAR HITCH
36"
1 5/8" TYP.
WELD SHIELD MOUNT
STRAP (ITEM 7) TO
HITCH SUPPORT (ITEM 6)
6
TELESCOPING
REAR HITCH
1
7
2
5
4
5
4
3
2
4
5
1
5
4
38"
1 1/8" TYP.
TELESCOPING
REAR HITCH
3
7
WELD SHIELD MOUNT
STRAP (ITEM 7) TO
HITCH SUPPORT (ITEM 6)
6
ON ALL 38" MODELS
ON ALL 36" MODELS
ON ALL 30" MODELS
MOUNTING ROLLING SHIELD AND ROTARY HOE WHEEL
RIGID TOOLBAR MOUNTING ALL SERIAL NO. MODELS
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1
2
3
4
810-002-363
810-002-364
950-003-021
951-001-008
LH Mount Bracket
RH Mount Bracket
Carriage Bolt 5/8-11 x 1 1/4
Hex Nut 5/8-11
2
2
8
8
5
6
7
952-001-005
810-002-212
810-001-551
Lock Washer 5/8 Inch
Hitch Support Weldment
Shield Mount Strap
8
2
4
DWG. NO. 2888
