Hiniker 6000 - Rigid Toolbar Mounting Rolling Shield and Rotary Hoe Wheel (Cont.)

Page 13
SERIES 6000 ROW CULTIVATOR
11/10
S
E
C
5
30"
LIFT ASSIST
3
1
2
5
4
LIFT ASSIST
3
36"
2
1
4
5
2
4
5
LIFT ASSIST
38"
1
3
ON ALL 36" MODELS
ON ALL 38" MODELS
ON ALL 30" MODELS
MOUNTING ROLLING SHIELD AND ROTARY HOE WHEEL
RIGID TOOLBAR MOUNTING ALL SERIAL NO. MODELS
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1
2
3
810-002-364
810-002-363
805-001-332
RH Mount Bracket
LH Mount Bracket
Center U-Bolt 5/8 x 7 5/8
2
2
4
4
5
951-001-008
952-001-005
Hex Nut 5/8-11
Lock Washer 5/8 Inch
8
8
DWG. NO. 2889
