Hiniker 6000 - Rigid Toolbar Mounting Folding Toolbar Mounting 8;30, 8;36-38,12;30 Serial No. Ending 100

Page 14
SERIES 6000 ROW CULTIVATOR
11/10
S
E
C
5
8, 11, 12
9
10
5, 6, 7
38" ALL MODELS
36" ALL MODELS
30" ALL MODELS
2
6
7
30
2
6
7
36
RIGHT SIDE HINGE SHOWN
2
38
7
6
5
5
5
NOTE: POSITION OF SLOT
MUST BE ON INSIDE
MOUNTING ROLLING SHIELD AND ROTARY HOE WHEEL
ROLLING SHIELDS & ROTARY HOE
WHEEL MOUNT BRACKETS, WITH OR
WITHOUT TELESCOPING REAR HITCH
OR LIFT ASSIST.
1
1
1
4
4
3
3
3
3
3
4
4
4
4
3
13
TOP VIEW
RIGID TOOLBAR MOUNTING FOLDING TOOLBAR MOUNTING
8/30, 8/36-38,12/30 SERIAL NO. ENDING 100
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1
2
3
4
5
6
7
8
810-002-310
810-002-311
810-002-364
810-002-363
950.001-087
952-001-005
951-001-008
950-001-029
Mount Plate
Mount Bracket Weldment
RH Mount Bracket
LH Mount Bracket
Hex Head Cap Screw 5/8-11 x 1-1/2
Lock Washer 5/8
Hex Nut 5/8-11
Hex Head Cap Screw 3/4-10 x 1-3/4 Gr. 5
2
2
A/R
A/R
16
A/R
A/R
4
9
10
11
12
13
952-002-008
810-002-421
952-001-006
951-001-009
805-001-329
Flat Washer 3/4 Inch
Bushing
Lock Washer 3/4 Inch
Hex Nut 3/4-10
Spacers
* NOTE: Spacers Used To Align Shields Over
The Row
2
2
4
4
A/R
DWG. NO. 2868
