Hiniker 6000 - Concrete Blocks

Page 20
SERIES 6000 ROW CULTIVATOR
11/10
S
E
C
5
1
CONCRETE BLOCKS
DWG. NO. 1666
7
1
3
5
1
8
6
4
2
ASSEMBLED VIEW OF EXTRA
DOWN PRESSURE ASSEMBLY
DOWN PRESSURE SPRING ASSEMBLY
DWG. NO. 2887
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1
2
3
4
5
81004102
61004106
81004103
81004104
81004105
Washer
Top Slide Anchor
Tube
Cover
Double Torsion Spring
2
1
1
1
1
6
7
8
031-30078
950-001-259
10304
81004117
Slotted Hex Self Tapping Screw #8 x 1/2 AB
Hex Head Cap Screw 1/2-13 x 8 Gr. 5
Lock Nut 1/2-13
Down Pressure Spring Assembly (2 Row)
4
1
1
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1 810-001-176 Concrete Blocks 2
