Hiniker 6000 - Vertical Wing Fold Stop Assembly

Page 21
SERIES 6000 ROW CULTIVATOR
11/10
S
E
C
5
CENTER SECTION
4" CYL=10 5/16 LG
5" CYL=8 7/16 LG
6
WING SECTION
CYL CLEVIS
1 1/2 REF.
7
3,4,5
1
(IN STORAGE
POSITION)
2
44
8
VERTICAL WING FOLD STOP ASSEMBLY
8/36-38-40,12/30 SERIAL NO. ENDING 101 OR HIGHER
12/36-38,12/40,16/30 SERIAL NO. ENDING 100 OR HIGHER
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1
2
3
4
5
6
81004375
81004379
875-001-038
952-001-006
951-001-009
81004377
Wing Stand Weldment
Pin Assembly
U-Bolt 3/4-10 x 7 3/4
Lock Washer 3/4
Hex Nut 3/4-10, 81004377
Cylinder Spacer 2-5/8 O.D. x 8 7/16
(Fits 5 x 16 Cylinder)
2
2
4
8
8
2
7
8
81004445
950-008-001
953-005-002
81004355
Cylinder Spacer 2 3/8 O.D. x 10 5/16
(Fits 4 x 16 Cylinder)
Hex Socket Head Set Screw 3/8-16 x 3/8
Hair Pin Cotter .178 x 3 9/16
Complete Vertical Wing Fold Stop Assembly
2
2
2
2
DWG. NO. 3013
