Hiniker 6000 - Plastic Shield

Page 26
SERIES 6000 ROW CULTIVATOR
11/10
S
E
C
5
FRONT
13
17
25
11
18
12
18
8
1
SEE DETAIL A
DETAIL A
21
3
4,5
20
16
3
21
6
2
6
23
15
19
10
14
9
14
19
22
1
30
33
32
33
32
28
27
34
29
26
35
7
9
24
27
31
NO SLOT
20"
PLASTIC SHIELD
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
700-14403
601189
953-001-007
810-001-834
810-001-835
81004540
81002707
81002709
81002715
81002741
81004524
81004529
81004530
950-001-084
950-002-008
950-001-113
030-12046
951-002-002
Hex Slot Head Self Tapping Screw #10 x 1/2
Extension Spring
Cotter Pin 3/16 x 1 1/2
RH Shield (Shown)
LH Shield
Rigid Link Weldment
Top Channel
Chain
Bushing
U-Bolt 3/8 x 1 7/8 Center
Rod Weldment
Frame Weldment/Skid Assembly
Plastic Skid
Hex Head Cap Screw 3/8-16 x 4 Gr. 5
Hex Head Flanged Whiz Lock Bolt 3/8-18 x 3/4
Hex Head Cap Screw 5/16-16 x 3/4 Gr. 5
Carriage Bolt 5/16-18 x 2 Gr. 2
Hex Head Flanged Whiz Lock Nut 5/16-18
4
2
4
1
1
4
2
2
4
4
2
2
2
6
2
4
2
6
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
951-002-003
952-002-002
952-002-008
953-005-002
81004538
805-001-725
950-005-020
950-001-246
952-001-004
951-001-007
81004682
81004683
950-001-060
031-21035
034-05147
81004671
81004686
Hex Head Flanged Whiz Lock Nut 3/8-16
Flat Washer 5/16 Inch WRT
Flat Washer 3/4 Inch WRT
Hair Pin Cotter .178 x 3 9/16
Stop Plate
Chain Connector
Hex Head Self Tapping Screw #10-16 x 3/4
Hex Head Cap Screw 1/2-13 x 7 1/2 Gr. 5
Lock Washer 1/2 Inch
Hex Nut 1/2-13
RH Mount Weldment
LH Mount Weldment
Hex Head Cap Screw 1/2-13 x 5 Gr. 5
Set Screw Square Head 3/8 x 1 3/4 Cup Point
Jam Nut 3/8-16
Mount Tube 30 Row
Spacer Tube
20
4
6
2
2
2
6
1
3
3
1
1
2
2
2
1
1
DWG. NO. 3171
