Hino 600 - COMPONENT LOCATOR

SERVICE BRAKE (FULL AIR BRAKE)BR02–88
COMPONENT LOCATOR
EN0680202D100007
OFFSET CLEVIS FOR FRONT AXLE SLACK ADJUSTER
BOOT
SMALL
CLEVIS PIN
ACTUATOR ROD
PISTON RETAINING
RING
ROLLER (PIN)
ACTUATOR PISTON
ACTUATOR
(ADJUSTING SLEEVE)
BOOT
RETAINING
CLAMP
LARGE
CLEVIS PIN
RETAINER CLIP
LARGE
CLEVIS PIN
STRAIGHT
OR OFFSET
CLEVIS
SMALL
CLEVIS PIN
RETAINER
CLIP
ACTUATOR
ASSEMBLY
RETAINER/SEAL
GEAR
FACE
SEAL
GREASE
FITTING
WORM
RETAINING
RING
WORM
GREASE
SEAL
HOUSING
WORM GEAR
MANUAL
ADJUSTING
NUT (END
OF WORM)
BUSHING
GASKET
PULL PAWL ASSEMBLY
(Replaces all previous pawl assemblies.)
NOTE:
Parts shown in this box are
not serviceable or interchangeable
with parts from earlier models.
SHTS068020200089
LARGE
CLEVIS PIN
SPRING
OFFSET CLEVIS
COTTER
PIN
SPRING
CLEVIS
COLLAR
LARGE
CLEVIS
PIN
SLACK
ADJUSTER
ARM
SMALL
CLEVIS PIN
ACTUATOR ROD
Use with
type 9 and 12
air chambers.
SHTS068020200090
