Hioki MEMORY HiLOGGER LR8450 Quick Start Guide

11
Specications
LR8450, LR8450-01 Memory HiLogger
General specications, Basic specications
Product warranty period 3 years
Accuracy guarantee period 1 year
Maximum number of
connectable modules
4 plug-in modules + 7 wireless modules*
* LR8450-01 only
Connectable modules
(Plug-in modules)
U8550 Voltage/Temp Unit
U8551 Universal Unit
U8552 Voltage/Temp Unit
U8553 High Speed Voltage Unit
U8554 Strain Unit
Connectable modules
(Wireless modules)
(LR8450-01 only)
LR8530 Wireless Voltage/Temp Unit
LR8531 Wireless Universal Unit
LR8532 Wireless Voltage/Temp Unit
LR8533 Wireless High Speed Voltage Unit
LR8534 Wireless Strain Unit
Internal buffer memory Volatile memory, 256 Mwords
Clock functionality Auto-calendar, automatic leap year recognition, 24-hour clock
Clock precision
(Precision of clock dis-
played by instrument as
well as start/stop times)
±1.0 s/day (at 23°C)
Time can be synchronized with an NTP server to which instrument is
connected.
Time axis accuracy ±0.2 s/day (at 23°C)
Backup battery
service life
At least 10 years for clock (reference value at 23°C)
Operating environment Indoors, Pollution Degree 2, altitude up to 2000 m
Operating temperature
and humidity range
−10°C to 50°C (14°F to 122°F), 80% RH or less (non-condensing)
(Charging temperature range: 5°C to 35°C)
Storage temperature
and humidity range
−20°C to 60°C (−4°F to 140°F), 80% RH or less (non-condensing)
Dimensions Without any modules: 272W × 145H × 43D mm (10.72″W × 5.71″H ×
1.69″D) (excluding protrusions)
With 2 modules:272W × 198H × 63D mm (10.71″W × 7.8″H × 2.78″D)
(excluding protrusions)
With 4 modules:272W × 252H × 63D mm (10.71″W × 9.92″H ×
2.48″D) (excluding protruding parts)
Mass Approx. 1108 g (39.08 oz.) (excluding battery pack)
Standards Safety: EN61010
EMC: EN61326 Class A
Vibration
resistance
JIS D 1601:1995:1995 5.3 (1)
Class 1: Passenger vehicles; conditions: Class A equivalent
Accessories Quick Start Manual, LOGGER Application Disc (Quick Start Manual,
Instruction Manual, Logger Utility, Logger Utility Instruction Manual,
Communication Instruction Manual), USB Cable, AC Adapter Z1014,
Precautions Concerning Use of Equipment that Emits Radio Waves
(LR8450-01 only)
Display
Display 7-inch TFT color LCD (WVGA 800 × 480 dots)
Display resolution
(with waveform
display selected)
Max. 20 divisions (horizontal axis) × 10 divisions (vertical axis)
(1 division = 36 dots [horizontal axis] × 36 dots [vertical axis])
Display language Japanese, English, Chinese, Korean
Backlight service life Approx. 100,000 h (Reference value at 23°C)
Backlight saver
Turns off backlight when no key is operated for a set amount of time.
Backlight brightness 5 levels (user-selectable)
Waveform
background color
Dark/light (user-selectable)
Power supply
Power
supply
AC adapter Z1014 AC Adapter (12 V DC ±10%)
AC Adapter rated supply voltage: 100 V to 240 V AC (as-
suming voltage uctuation of ±10%)
AC Adapter rated power supply frequency: 50 Hz/60 Hz
Battery LR8450 accommodates 2 batteries
Z1007 Battery Pack
(When used with AC Adapter, AC Adapter has priority)
Li-ion, 7.2 V, 2170 mAh
External
power supply
10 V to 30 V DC
Power con-
sumption
Normal power
consumption
Using Z1014 AC Adapter or 12 V DC external power sup-
ply, without Battery Pack
With LCD at maximum brightness: 8.5 VA
(instrument only)
With LCD backlight off: 7 VA (instrument only)
Maximum
rated power
When using the Z1014 AC Adapter
95 VA (including AC Adapter)
When using a 30 V DC external power supply
28 VA (while charging battery with LCD at maximum brightness)
When using the Z1007 Battery Pack
20 VA (with LCD at maximum brightness)
Continuous
operating
time
Battery With one Z1007 Battery Pack: Approx. 2 h (reference value at 23°C)
With two Z1007 Battery Packs: Approx. 4 h (reference value at 23°C)
Conditions: With one U8551 Universal Unit connected, back-
light on, voltage output off, and Z4006 connected
Charging
functionality
Charging is available when the Z1007 Battery Pack is attached and the
AC Adapter is connected.
Charging time: Approx. 7 h (reference value at 23°C)
Interface specications
The LAN interface and USB interface (function) cannot be used at the same time.
LAN
interface
IEEE 802.3 Ethernet, automatic 100Base-TX/1000Base-T detection
Auto MDI-X, DHCP, DNS support
Connector: RJ-45
Maximum cable length: 100 m
LAN func-
tionality:
Acquiring data and setting recording conditions with the Logger Utility
LAN
interface
LAN func-
tionality:
Conguring settings and controlling recording using communica-
tions commands
Manually acquiring data using the FTP server Acquiring les from a
connected SD Memory Card or USB Drive
Automatically sending data via FTP (FTP client)
Transferring les saved on a connected SD Memory Card or USB Drive
While measurement is in progress: Waveform les (binary, text)
After measurement has nished: Waveform les (binary, text),
numerical calculation result les
HTTP server function
Control mode (one instrument)
Displaying screen and remotely controlling instrument and
modules, starting/stopping measurement, acquiring data via FTP,
conguring comment, updating instrument and modules
Browsing mode (up to four instruments)
Displaying screen, measurement status, and comments
Email transmission
Start trigger, stop trigger, alarm, power outage recovery, internal buffer,
memory full, media full, wireless unit communication interruption, bat-
tery low, and periodic mail transmission. Instantaneous values can be
attached for start trigger, stop trigger, alarm, and periodic transmission.
Emails can be sent regularly at the following intervals: 30 min., 1 h,
12 h, 1 day.
NTP client function
Time synchronization with an NTP server
Regular synchronization intervals: 1 h, 1 day
Pre-measurement synchronization function
Wireless
LAN
interface
(LR8450-01
only)
IEEE 802.11b/g/n
Communications range: 30 m, line of sight
Encryption function: WPA-PSK/WPA2-PSK, TKIP/AES
Usable channels: 1 to 11
Auto-connect function: Wireless LAN function can be toggled on and off.
Supported modes: Access point, station, wireless unit connectivity
Devices that can be connected in wireless unit connectivity mode: Wireless
units or PC/tablet
Wireless unit and PC/tablet connectivity are exclusive.
Wireless
LAN func-
tionality:
Conguring settings and controlling recording using
communications commands
Manually acquiring data using the FTP server
Acquiring les from a connected SD Memory Card or USB Drive
Automatically sending data via FTP (FTP client)
Transferring les saved on a connected SD Memory Card or USB Drive
HTTP server function
Control mode (one instrument)
Displaying screen and remotely controlling instrument and mod
-
ules, starting/stopping measurement, acquiring data via
FTP, conguring comment, updating instrument and modules
Browsing mode (up to four instruments)
Displaying screen, measurement status, and comments
Email transmission
Start trigger, stop trigger, alarm, power outage recovery, internal buffer,
memory full, media full, wireless unit communication interruption, bat-
tery low, and periodic mail transmission. Instantaneous values can be
attached for start trigger, stop trigger, alarm, and periodic transmission.
Emails can be sent regularly at the following intervals: 30 min., 1 h,
12 h, 1 day.
NTP client function
Time synchronization with an NTP server
Regular synchronization intervals: 1 h, 1 day
Pre-measurement synchronization function
USB
interface
(host)
Standard compliance: USB 2.0 compliant
Connectors: Series A receptacle × 2
Guaranteed-operation options: Z4006 USB drive (16 GB)
File system: FAT16, FAT32
Connectable devices: keyboard, mouse, hub (1 layer), USB drive (1 port only)
USB
interface
(function)
USB standard: USB 2.0 compliant
Connector: Series mini-B receptacle
USB functionality: Data acquisition, condition settings used with the Logger
Utility software (bundled)
Conguring settings and controlling recording using com-
munications commands
USB drive mode: Transferring data from a connected SD memory card to a computer
SD card
slot
Standard compliance: SD standard-compliant slot × 1 (with SD memory card/
SDHC memory card support)
Guaranteed-operation options: Z4001 (2 GB), Z4003 (8 GB)
File system: FAT16, FAT32
External control terminals
Terminal block Push-button type terminal block
External
I/O
Number of
terminals
4, Non-isolated (same GND as instrument)
Input Input voltage 0 V to 10 V DC
Slope Rising/falling (user-selectable)
Functionality Choose from off, start, stop, start/stop, trigger
input, event input.
Output
Output format Open-drain output (with 5 V voltage output)
Maximum switching
capacity
5 V to 10 V DC, 200 mA
Functionality Trigger output
Alarm output
Output format Open-drain output (with 5 V voltage output)
Maximum switching capacity 5 V to 30 V DC, 200 mA
Number of terminals 8, Non-isolated (same GND as instrument)
Voltage output Output voltage Off, 5 V, 12 V, 24 V* (user-selectable)
Supply current: Max. 100 mA each
*: 24 V output can be selected for the VOUT-
PUT1 terminal only.
Number of terminals 2, Non-isolated (same GND as instrument)
GND terminal Number of terminals 10 (common GND)
ES France - Département Tests & Mesures - 127 rue de Buzenval BP 26 - 92380 Garches
Tél. 01 47 95 99 45 - Fax. 01 47 01 16 22 - e-mail: tem@es-france.com - Site Web: www.es-france.com

Hioki MEMORY HiLOGGER LR8450 Specifications

General

Storage Media	SD card (up to 32 GB)
Measurement Types	Voltage, Temperature, Resistance, Strain, Pulse, Logic
Sampling Rate	1 ms to 1 hour
Interface	LAN, USB, SD card slot
Power Supply	100 to 240 V AC, 12 V DC
Resolution	16-bit
Voltage Range	±10 mV
