Hioki MEMORY HiLOGGER LR8450 Quick Start Guide

Standard model (designed for use with plug-in units only)
LR8450
2
You can add up to 4 plug-in units and provide 120 channels
of measurement
Two models:
Standard Model and Wireless LAN Model
Each VOLTAGE/TEMP UNIT U8552 accepts 30 channels of input. Add four units for 120 channels of measurement.
Plug-in units
Conguration example: 120 channels
VOLTAGE/TEMP UNIT U8552 × 4
ES France - Département Tests & Mesures - 127 rue de Buzenval BP 26 - 92380 Garches
Tél. 01 47 95 99 45 - Fax. 01 47 01 16 22 - e-mail: tem@es-france.com - Site Web: www.es-france.com

Hioki MEMORY HiLOGGER LR8450 Specifications

General

Storage Media	SD card (up to 32 GB)
Measurement Types	Voltage, Temperature, Resistance, Strain, Pulse, Logic
Sampling Rate	1 ms to 1 hour
Interface	LAN, USB, SD card slot
Power Supply	100 to 240 V AC, 12 V DC
Resolution	16-bit
Voltage Range	±10 mV
