HIOS BLG-BC2 Series - Default Chapter; Table of Contents

02
03 Important Safety Instructions
05 Checking Supplied Accessories
06 Setting Up the Device
Connecting the Cord
Installing with the Stand (BLG-7000BC2-
GT-S)
Attaching a Bit
Changing the Start Mode (for BLG-5000BC2
Series /BLG-7000BC2 Series)
BLG-5000BC2 Series
BLG-7000BC2 Series
10 Parts and Their Functions
BLG-4000BC2 Series
BLG-5000BC2 Series
BLG-7000BC2
BLG-7000BC2-GT (-S/-HANDLE)
Operation Panel
Stand / Handle
13 Basic Operations
How to Change Rotation Speed
14 Setting the Torque
BLG-4000BC2 Series
Output Torque Guide (HI Input)
How to Change to Smaller Torque
BLG-5000BC2 Series /BLG-7000BC2
Output Torque Guide (HI Input)
BLG-7000BC2-GT
Output Torque Guide (HI Input)
18 Setting the Pass / Fail Criteria
Setting by Direct Teaching
Setting by Manual Procedure
21 Setting Screw Counter
23 Setting Menu List
How to Operate Setup Mode
<Counter>
<Screw Counter>
<Minimum Pulse>
<Maximum Pulse>
<Work Reset Timer>
<Count Timer for Reverse Rotation>
<System>
<Pulse Detection>
<Total Torque-ups (count)>
<Inactive Time of Torque-up>
27 Connecting the Special Cable (Option)
Checking Supplied the Cable Accessories
Connecting to Screwdriver (BLG-4000BC2/
BLG-5000BC2 Series)
Connecting to Screwdriver (BLG-7000BC2)
31 Saving Screw Fastening Data
System Requirements
Screen of Connection
Connecting to Screwdriver
Sending Command
Work Monitor
Screen of Administration
Specications of Communication by Special
Cable
Message Format
Communication Command / List of
Messages
43 Troubleshooting
Common Problems
When the Messages Below Are Displayed
Want to See the Device Version
45 Maintenance
About BLG-7000BC2-GT
46 Specications
BLG-4000BC2 Series
BLG-5000BC2 Series
BLG-7000BC2
BLG-7000BC2-GT
51 Notice
Table of Contents
