The CL-2000 (SS-2000) Electric Screwdriver have
‘Double nut system’ (Nut xing ring and Torque adjust-
ing nut) to avoid loosening from shock or vibration to
the driver. To adjust those two nuts, follows
①
to
③
steps below.
At rst, stop the Nut xing ring upper
surface to t the graduation, if you
want to adjust.
Then turn the Torque adjusting nut so
as to push up the Nut xing ring.
Lastly, to avoid the loosening of the
‘Torque adjusting nut’ strongly fas-
ten the Nut xing ring’ by holding the
‘Torque adjusting nut’.
5. Push-to-Start Type
Both the models of Driver have Push-to-Start type that is
designed to start by causing a proper thrusting pressure on
the bit in place of pressing the Switch Lever by the fore-
nger. Drivers of this type are identied by the additional
sign PS following the principal Push-to-Start type models.
The PS type, therefore, has no lever for starting. All other
functions remain same as the principal type.
Usersofthistypeisspecicallycautionedtodisconnectthecord
to shut off power when handling the Quick Change Collet for
replacing bit to avoid danger from surprising starting.
6. Power Supplies
The power pack for CL Drivers requires two basic func-
tions: (1) to convert local AC power to lowered DC Power
and (2) to shut off the power by automatical reaction to the
pulse emitted from the Driver at the moment the torque at
work reaches the regulated limit. The function (2) can be
performed, if so opted, by a ready-made unit called Control
Box CB-105 installed separately from the unit for the func-
tion (1).
