Please carry out the following steps to install the
swivel seat assembly:
Attach the swivel seat assembly to the drive unit
with four fixing screws.
Connect the armrest controls, swivel seat switch
and swivel seat motor to the drive unit using plug-
in connections.
Insert the seat assembly between the U-bolts of
the drive unit, as shown in the pictures.
Ensure that no cables are damaged.
Fix the seat assembly in position at the side with
the four hexagon socket screws.
