30
EAGLE 20
Release
09
04/2012
3 Technical data
General technical data
Dimensions
W × H × D
EAGLE 20... 2.36 in. × 5.71 in. × 4.92 in.
(60 mm × 145 mm × 125 mm)
Weight EAGLE 20... 21.16 oz - 22.22 oz (depending on variant)
(600 g - 630 g)
Power supply Redundant power supply
Safety extra-low voltage (SELV), redundant inputs disconnected.
Relevant for North America: NEC Class 2 power source max. 5A.
Operating voltage Rated voltage range DC
12 to 48 V DC
Max. voltage range DC
min. 9.6 to max. 60 V DC
Rated voltage range AC
24 V AC
Max. voltage range AC
min. 18 to max. 30 V AC
Back-up fuse Nominal rating:
3,15 A for each voltage input
Characteristic:
slow blow
Insulation voltage between operating voltage
connections and housing
800 V DC
Protective elements limit the insulation
voltage to 90 V DC (1 mA)
“FAULT”
signal contact
Switching current max. 1 A, SELV
Switching voltage max. 60 V DC or max. 30 V AC, SELV
Relevant for North America: NEC Class 2
Environment Storage temperature
(ambient air)
−40 °F ... +158 °F (−40 °C ... +70 °C)
Humidity 10% ... 95%
(non-condensing)
Air pressure Up to 2000 m (795 hPa), higher altitudes
on request
Operating
temperature
Surrounding air +32 °F ... +140 °F (0 °C ... +60 °C)
Protection classes Laser protection Class 1 according to EN 60825-1 (2007)
Protection class IP 20
Mounting 35 mm DIN rail (DIN EN 60175)
Pollution degree 2
