EAGLE 20
Release
09
04/2012
MM = Multimode
SM = Singlemode
Power consumption/power output
Order numbers
Interfaces
Ports Wave
length
Fiber System
attenuati
on
Example
for F/O
line
length
a
a. including 3 dB system reserve when compliance with the fiber data is observed
Fiber
attenuation
BLP/
dispersion
MM 1300 nm 50/125 µm 0-8 dB 0-5 km 1.0 dB/km 800 MHz*km
MM 1300 nm 62.5/125 µm 0-11 dB 0-4 km 1.0 dB/km 500 MHz*km
SM 1300 nm 9/125 µm 0-16 dB 0-30 km 0.4 dB/km 3.5 ps/(nm*km)
Table 4: LWL port 100BASE-FX
Device variant Power
consumption
at 24 V DC
Power output
at 24 V DC
Power
consumption
at 24 V AC
Power output
at 24 V AC
...TX/TX 6.9 W 23.5 Btu (IT)/h 7.2 W 24.6 Btu (IT)/h
...TX/MM
...MM/TX
...TX/SM
8.1 W 27.6 Btu (IT)/h 8.1 W 27.6 Btu (IT)/h
...MM/MM 9.5 W 32.4 Btu (IT)/h 9.6 W 32.8 Btu (IT)/h
Device Order number
EAGLE 20 TX/TX 943 987-001
EAGLE 20 TX/MM 943 987-002
EAGLE 20 TX/SM 943 987-003
EAGLE 20 MM/TX 943 987-004
EAGLE 20 MM/MM 943 987-005
EAGLE 20... V.24 port: external management, modem
terminal block, 6-pin: signal contact, max. 1 A, 24 V
and voltage supply
USB interface: ACA 21-USB
Additionally 2 type-
dependent ports each
Up to two 10/100 Mbit/s twisted pair (TP/TX) ports with RJ45
sockets and/or up to two 100 Mbit/s FX ports (multimode or
singlemode) with DSC connections
