Hisense HME8C55S User Manual

Overview
Technical Specifications
Model
HME8C55S
Name
LCD monitor
LCD
monitor
panel
Size
55 inches
Panel type
Color LCD panel
Diagonal length
139 cm
Backlight
LED
Screen size
1209.6 mm x 680.5 mm
Screen ratio
16:9
Resolution
3840x2160
Max. display colors
1.07 billion colors
Pixel pitch
0.315 mm (horizontal) x 0.315 mm (vertical)
Brightness
600 cd/m
2
Contrast
4000:1 (typ.)
Response time
6 ms (G to G) (typ.)
Visible angle
≥ 178° (CR 10:1)
Factory default brightness
400±20 cd/m
2
Input signal interfaces
HDMI x 1
DVI x4
DP x 1
VGA x 1
SOG x2
3G-SDI/HD-SDI x 1
Output signal interfaces
HDMI x 1
3G-SDI/HD-SDI x 1
Interaction interface
RS485x2
Power
supply
Input voltage
220 V, 50 Hz
Typical power
220 W
Machine dimension (W x H x T)
1260 mm x 756 mm x 90 mm
Product weight (net)
37 kg
Fixing equipment
Meeting the requirements of compatible design for hanging on the
wall, lifting, and embedded in the wall
Pitch (VESA standard)
400 mm x 200 mm
Environment
conditions
Temperature
Operating: 10°C to 35°C
Storage/Transportation: –20°C to +60°C
Humidity
Operating: 20% to 85% RH
Storage/Transportation: 10% to 90% RH
Atmospheric
pressure
Working atmospheric pressure: 700-1060 hPa
Storage atmospheric pressure: 200-1060 hPa
Execution standard
Q/0202RSR 631
3

Hisense HME8C55S Specifications

General

Brand	Hisense
Model	HME8C55S
Category	Monitor
Language	English
