Water Dispenser(only for appliance with
dispenser)
The water dispenser, located in the fridge
door, is for storing drinking water. With this
appliance you can obtain chilled water
easily without opening the refrigerator. You
should review of following tips.
Before using this appliance for the first time,
Before assembling, please drain the water
inside the tank, and check whether the
washer reversed or not.
1. Insert the head into the hole.
2. Fit the tank along the guides on the door.
3.Press down two side of the tank.
4. When you hear a click sound, that
means the installation is completed.
you should use it based on following
instructions:
1. Hold the two sides of the water tank
tightly, then pull up the water tank by
shaking up and down.
2. Unscrew the head, then clean it and the
inside of water tank.
21
dispenser Pad
water storage box head
water storage box cover
Before using
Assembling
head
Slot
Guide
① ②
③
④
Warning!
Filling water
Caution!
Receiving water
Warning!
Door handles(only for appliance with
handle)
1. Be careful not to press on the head;
2. when fitting the water tank, ensure the
head inserted into the hole first.
1.Open the cover by rotating it upwards.
2.Fill the water.
Do not Fill the water above the level
suggested. Otherwise, it may overflow even
when the cover is close.
You should use the correct cups to receive
water underneath the water dispenser.
Don’t push the dispenser lever forward
without cup, it may cause the water leak
from the dispenser.
For the convenience of transportation, the
door handles are separately provided in a
plastic bag, you can install the handles as
follows.
1.Lever screw covers on the left side of the
door, and put them back to the plastic
bag.
2.Match the handle on the left side of the
door, keeping axes of screw holes in the
handle and the door in a line.
3.Fix the handle with the special screws
provided in the plastic bag, then install the
handle covers.
cover
dispenser pad
suggested position
Middle rack
