MH-012 Ecomaster Clima user manual
1. Functional description
In Air Conditioning Operation, the variables are:P
Temperature set.
Evaporators speed
Flaps
De-humidification
Ecologic mode - Block compressor.
Any variation in the speed, position of the flaps, De-humidification or Compressor blocking places the air conditioning
system in semi-automatic mode and it can be switched to fully automatic mode by pressing the AUTO button.
Temprature set 1.1.
The Temperature can be set between 17ºC and 27ºC (63-82ºF) using the (8)and (7)keys.
When the temperature level is set below 17ºC (63ºF), the system engages forced chill mode (LO) and acti-
vates its maximum cooling power. (the screen displays LO)
When the temperature is set above 27ºC (82ºF), the system engages forced heat mode (HI) and activates
its maximum heating power (the screen displays HI).
Varying the speed of the Evaporator Ventilators 1.2.
The speed of the evaporators can be varied from levels 1 to 3. When the speed is altered, the system goes
into manual mode and the led located next to key (1) will be switched off.
If the key (1) is pressed, the system automatically recovers the corresponding speed and the led will
shine again to indicate manual operation.
To alter the speed, press key (2). Pressing it once will display the current speed on the screen; if it is
pressed again, the value of the speed will be increased in a closed loop (from 3 it will change to 1).
Note:
