MAINTENANCE AND ADJUSTMENT OF THE EV
100
Protection function
Protection Item
Input Over-voltage Protection,Input
Under-voltage Protection,Output Over-
voltage Protection, Output Over-current
Protection,Over-temperature
Protection,Short-circuit Protection.
Standard
Limit
Structure
non-output opposing connection
All-closed, no fan, natural air cooling
Circuit breaker
Type
Controller’s main fuse
Cable’s main fuse
Fuse
425A
30A
----
TIGHTENING TORQUES
Chassis tightening torques
Part to be tightened
Thread
size
Tightening torque
Remarks
Nm
m ·
kg
ft · lb
Rubber connecting bracket 1(or 2) and frame
M10
52
5.2
37
Engine and Rubber connecting bracket 2 (front)
M10
52
5.2
37
M6
10
1.0
7.2
Engine and Rubber connecting bracket 1 (rear)
M8
33
3.3
24
M6
10
1.0
7.2
Rear upper arm and frame
M10
45
4.5
32
Rear lower arm and frame
M10
45
4.5
32
Rear knuckle and rear upper arm
M10
45
4.5
32
Rear knuckle and rear lower arm
M10
45
4.5
32
