MAINTENANCE AND ADJUSTMENT OF THE EV
101
Rear shock absorber and frame
M12
80
8.0
58
Rear shock absorber and rear lower arm
M12
80
8.0
58
Rear Balancing pole and frame
M8
32
3.2
23
ball head of Rear Balancing pole and Rear Balancing
pole
M10
56
5.6
40
ball head of Rear Balancing pole and rear lower
arm
M10
56
5.6
40
Differential gear case and frame
M10
55
5.5
40
Differential gear case filler plug
M14
23
2.3
17
Differential gear case drain plug
M10
10
1.0
7.2
Universal joint yoke and drive pinion gear
M14
62
6.2
45
Differential motor and differential gear case cover
M8
13
1.3
9.4
Differential gear case cover and differential gear case
M8
25
2.5
18
Rear driving axle gear case and frame
M10
70
7.0
51
Rear driving axle gear case filler plug
M20
23
2.3
17
Rear driving axle gear case drain plug
M10
20
2.0
14
Ring gear bearing housing and final drive gear
case
M8
23
2.3
17
M10
40
4.0
29
Ring gear stopper nut
M8
16
1.6
11
Bearing retainer and final gear pinion gear bearing
housing
M65
170
17.0
125
Left-hand
threads
Coupling gear and final drive pinion gear
M12
80
8.0
58
Front upper arm and frame
M10
45
4.5
32
Front lower arm and frame
M10
45
4.5
32
Front shock absorber and frame
M10
45
4.5
32
Front shock absorber and front upper arm
M10
45
4.5
32
Steering shaft assembly and steering Cross
gimbal
M8
22
2.2
16
Steering assembly and steering Cross gimbal
M8
22
2.2
16
Steering assembly and frame
M10
48
4.8
35
Steering shaft assembly and frame
M8
21
2.1
15
