MAINTENANCE AND ADJUSTMENT OF THE EV
102
Steering wheel and steering shaft assembly
M12
35
3.5
25
Steering knuckle and front upper arm
M12
30
3.0
22
Steering knuckle and front lower arm
M12
30
3.0
22
Tie-rod locknut
M12
40
4.0
29
Steering knuckle and tie-rod
M12
39
3.9
28
Front lower arm protector board and front lower
arm
M6
7
0.7
5.1
Seat belt and frame
M10
59
5.9
43
Part to be tightened
Thread
size
Tightening torque
Remarks
Nm
m ·
kg
ft · lb
Seat belt and ceiling (enclosure)
7/16
59
5.9
43
Front wheel and front wheel hub
M10
55
5.5
40
Front wheel hub and constant velocity joint of half
shaft
M20
260
26.0
190
Stake
Steering knuckle and brake disc guard
M6
7
0.7
5.1
Front brake caliper and front wheel steering
knuckle
M10
48
4.8
35
Front brake hose union bolt
M10
27
2.7
19
Front brake hose holder and steering knuckle
M6
7
0.7
5.1
Front brake hose holder and front upper arm
M6
7
0.7
5.1
Front brake hose holder and frame
M6
7
0.7
5.1
Front brake pad holding bolt
M8
18
1.8
13
Front brake disc and front wheel hub
M8
30
3.0
22
Front brake caliper bleed screw
M6
6
0.6
4.3
Rear wheel and rear wheel hub
M10
55
5.5
40
Rear wheel hub and constant velocity joint of half
shaft
M20
260
26.0
190
Stake
Rear brake hose and frame
M6
7
0.7
5.1
Brake pipe and brake master cylinder
M10
19
1.9
13
Pedal holder assembly and frame
M8
16
1.6
11
