MAINTENANCE AND ADJUSTMENT OF THE EV
103
Brake master cylinder and pedal holder assembly
M8
16
1.6
11
Secondary brake master cylinder kit stopper bolt
M6
9
0.9
6.5
Brake rod locknut
M8
17
1.7
12
Rear brake disc and brake disc Install seat
M6
10
1.0
7.2
Rear brake pad holding bolt
M8
17
1.7
12
Rear brake caliper and Install seat
M10
40
4.0
29
Rear brake hose union bolt
M10
27
2.7
19
Parking brake case and rear brake caliper
M8
22
2.2
16
Parking brake lever assembly and frame
M6
7
0.7
5.1
Rear brake caliper bleed screw
M6
5
0.5
3.6
Upper instrument panel and frame
M6
7
0.7
5.1
Support frame (enclosure) and frame
M10
64
6.4
46
Support frame (enclosure) and side frame
(enclosure)
M10
64
6.4
46
Top frame (enclosure) and side frame (enclosure)
M10
64
6.4
46
Seat support and frame
M8
16
1.6
11
Footrest plate and frame
M6
7
0.7
5.1
Cover gearcase
M12
80
8.0
58
Controller
M8
16
1.6
11
GENERAL TIGHTENING TORQUE SPECIFICATIONS
This chart specifies tightening torques for standard fasteners with a standard ISO
thread pitch. Tightening torque specifications for special components or assemblies are
provided for each chapter of this manual. To avoid warpage, tighten multi-fastener
assemblies in a crisscross pattern and progressive stages until the specified tightening
torque is reached. Unless otherwise specified, tightening torque specifications require
clean, dry threads. Components should be at room temperature.
