MAINTENANCE AND ADJUSTMENT OF THE EV
- 112 -
Brake pad wear limit ○,a
1.5 mm (0.06 in)
3. Operate the brake pedal.
4. Install:
·front wheels
CHECKING THE REAR BRAKE PADS
1. Check:
·brake pads
Wear indicator groove ○,
a
almost
disappeared Replace the brake pads as a
set.
Refer to “FRONT AND REAR BRAKES” in
chapter 5.
Brake pad wear limit ○,a
1.5 mm (0.06 in)
1. Operate the brake pedal.
CHECKING THE BRAKE HOSES AND
BRAKE PIPES
1. Remove:
·seat
·console
Refer to “SEATS” in chapter 5
2. Lift the hood up.
3. Lift the cargo bed.
4. Check:
·front brake hoses ①
·rear brake hoses ②
Cracks/wear/damage Replace.
