MAINTENANCE AND ADJUSTMENT OF THE EV
- 117 -
·Final gear oil drain bolt ②
·Fill:
final gear case
Periodic oil change
0.25 L (0.22 Imp qt)
Total amount
0.28 L (0.25 Imp qt)
WARNING :
Take care not to allow foreign material to
enter the final gear case.
·Install:
oil filler plug and Final gear oil drain bolt
20 Nm (2.0 m·kgf, 14 ft·lbs )
CHECKING THE DIFFERENTIAL GEAR OIL
1. Place the vehicle on a level surface.
2. Remove:
Remove the differential gear oil filler bolt
and check the oil level. It should be up to
the brim of the filler hole. If the level is low,
add sufficient oil of the recommended type
to raise it to the specified level
·Differential gear oil drain bolt ①
3. Check:
·oil level
