MAINTENANCE AND ADJUSTMENT OF THE EV
Oil level should be up to the brim of hole.
Oil level low Add oil to proper level.
WARNING
:
Take care not allow foreign material to
enter the differential gear case.
4. Install:
·oil filler plug
23 Nm (2.3 m · kg, 17 ft · lb)
CHANGING THE DIFFERENTIAL GEAR OIL
1. Place the vehicle on a level surface.
2. Place a receptacle under the differential
gear case.
3. Remove:
·Differential gear oil drain bolt ①
2. Drain:
·differential gear oil
5. Install:
·drain plug
10 Nm (1.0 m · kg, 7.2 ft · lb)
NOTE:
Check the gasket (drain plug). If it is
damaged, replace it with new one.
6. Fill:
·differential gear case
Periodic oil change
0.25 L (0.22 Imp qt, 0.26 US qt)
Total amount
