Excessive play Replace the steering
shaft assembly.
• tie-rod ends
Turn the steering wheel to the left and right
until it stops completely, and then move the
steering wheel slightly in the opposite
direction. Tie-rod end (s) have vertical play
Replace the tie-rod end(s).
• Raise the front end of the vehicle so that
there is no weight on the front wheels.
• Check:
Ball joints and/or wheel bearings Move the
wheels laterally back and forth. Excessive
free play Replace the front arms (upper
and lower) and/or wheel bearings.
ADJUSTING THE TOE-IN
1. Place the vehicle on a level surface.
2. Measure:
• toe-in
Out of specification Adjust.
NOTE:
Before measuring the toe-in, make sure
that the tire pressure is correct.
