Hisun HS5DUTV-2 - Page 189

CHASSIS
- 189-
No.
Part Name
Qty
Remarks
11
Ignition switch assy.
1
12
Horn earth wire
1
13
Direction gas spring assembly
1
14
Step slotting pin Φ8×34
1
15
Cotter pin Φ5×1
2
16
Direction of the seat
1
17
Hexagon flange bolt M10×1.25×16
3
18
Bolts M6×Φ10×2.5×30.5
2
19
Metal insert hexagon lock nut with flange M6×1.25
2
20
Step slotting pin Φ8×45
1
21
Steering column cover Ⅲ
1
22
Steering column cover Ⅱ
1
23
With disc six angle bolts M6×12
2
