Hisun HS5DUTV-2 - Page 190

CHASSIS
- 190-
No.
Part Name
Qty
Remarks
24
Cross small plate head tapping screw ST3.9×13
3
25
Direction drive shaft assembly
1
26
Hexagon bolt with flange M8×30
1
27
Metal insert hexagon locknut with flange M12×1.25
1
28
Round head screw with cross M4×8
1
29
Horn spring
1
30
Connection strap for horn
1
31
Washer Φ10×Φ20×2
3
