Hisun HS5DUTV-2 - Page 288

ELECTRICAL COMPONENTS
- 288 -
No.
Part Name
Qty
Remarks
11
CirclipD0=30
4
12
Spring washer Φ12
4
13
Hexagon nut M12×1.25
4
14
Cotter pin 2.5×30
4
15
Front left upper rocker arm
1
16
Front right upper rocker arm
1
17
Hexagon flange bolt M10×1.25×230
2
18
Turnup bush Φ15.5×Φ19
4
19
Columniform bush Φ10.2×Φ15×211
2
20
Front right lower frame member
1
21
Front right upper frame member
1
22
Left front sway frame member
1
23
Front left bottom frame member
1
