Hitachi 50VS810 - Input

USEFUL INFO
76
Inputs:
•
Power Input . . . . . . . . . . . . . .AC 120V, 60Hz
•
Stand-by Power . . . . . . . . . . . . . . . . . .0.6W
• Power Consumption
- Refer to rear panel at the back of the T.V.
• Antenna input impedance . . . . . . . . .75 Ohm
• Channel coverage . . . . . . . . . . . . . . . .181ch.
VHF-Band . . . . . . . . . . . . . . . . . . . . . .2 ~ 13
UHF-Band . . . . . . . . . . . . . . . . . . . . .14 ~ 69
CATV Mid Band . . . . . . . . . . . . . . .A-5 ~ A-1
. . . . . . . . . . . . . . . . . . . . . . . . . . . .A-I
Super Band . . . . . . . . . . . . . . . . . . . . . .J-W
Hyper Band . . . . . . . . . . . . . . . .W+1 - W+28
Ultra Band . . . . . . . . . . . . . . . .W+29 - W+84
• Video . . . . . . . . . . . . . . . . .1.0Vp-p, 75 Ohm
• S-Video
Luminance (Y) . . . . . . . . . .1.0Vp-p, 75 Ohm
Chrominance (C) . . . . . . .0.286Vp-p, 75 Ohm
• Component Video
Luminance (Y) . . . . . . . . . . . . . . .1.0Vp-p, 75 Ohm
Chrominance (P
B
/P
R
) . . . . . . . . .0.7Vp-p, 75 Ohm
• Audio input Impedance . . . . . . . . . .47k Ohm
• Average input level . . . . . . . . . . . . . . . . .470mVrms
• HDMI . . . . . . . . . . . . . . . . . . . . . . . . . . .HDMI 19pin
Dimensions:
50VS810 60VS810 70VS810
• Height (in.) 28 11/16 33 9/16 40 9/16
(mm) 728.0 853.0 1030
• Width (in.) 55 3/8 64 1/8 73 5/8
(mm) 1,407.0 1,629.0 1,870.0
• Depth (in.) 16 6/16 19 1/16 23 5/8
(mm) 415.8 483.8 600
• Weight (lbs.) 110.2 132.3 198.4
(kg) 50.0 60.0 90.0
NOTE: Due to improvements, specifications in this operating
guide are subject to change without notice.
Outputs:
• Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.0Vp-p. 75 Ohm
• Audio (Fixed) . . . . . . . . . . . . . . . . . . . . . . . . . . .470mVrms, 1k Ohm
• S-Video
Luminance (Y) . . . . . . . . . . . . . . . . . . . . .1.0Vp-p, 75 Ohm
Chrominance (C) . . . . . . . . . . . . . . . . .0.286Vp-p, 75 Ohm
• Optical Out (Digital Audio) . . . . . . . . . . .1 optical connector
• Six Aspect Modes
• Closed Caption Decoder
• 2-Tuner Picture in Picture
• 2 Antenna Inputs (Either for Analog/Digital)
• Video Input Sensor
• 3 Dimensional Y/C Comb Filter
• Compatible with 1080i, 720p, 480p and 480i input signals.
• HDMI (High Definition Multimedia Interface) (High Bandwidth Digital Content Protection V1.1 compatible).
• Digital Audio Output (Dolby
®
Digital and PCM)
• Photo Input (for your digital camera).
• CableCARD
TM
compatible - Contact your local cable operator for more information.
• Technology.
*Licensed by BBE Sound, Inc. under USP4638258, 5510752 and 5736897. BBE and BBE symbol are registered
trademarks of BBE Sound, Inc. Manufactured under license from BBE Sound, Inc.
• Technology.
*SRS and symbol are trademarks of SRS Labs, Inc. SRS technology is incorporated under license from SRS Labs, Inc.
• Technology.
*Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby
Laboratories.
• Technology
*
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.
Features:
• Superfine Picture Quality
1280 Line Horizontal Resolution
• Remote (Controls many PVR/VCR brands, cable boxes, satellite boxes, and other audio equipment).
• New Easy-to-Use (3-Language) On-Screen Menu
• Full Set of Input Jacks, including S-VIDEO
• COMPONENT VIDEO: Y-P
B
/P
R
