SCREEN FRAME ASSY 2 (65F59/A/J) SCREEN FRAME ASSY 3 (65F59J)
① Screws T1T 4*18 P#MJ03587(24 Pcs.) ① Bottom Frame P#
TBD
Bottom Screen Holder P#QD38143
② Screen Assy P#
TBD
③ Ultrashield P#KR02076
④ Vertical Frame P#
TBD
⑤ Top Frame P# TBD
Top Screen Holder P#QD38133
108
TOP CORNER METAL(R)
TOP SUPPORT METAL
BOTTOM CORNER
BOTTOM SUPPORT METAL
BOTTOM CORNER METAL(L)
TOP CORNER METAL(L)
SLIDE OUT
SLIDE OUT
PULL OUT
METAL(R)
