Hitachi 57F59A - Page 180

PRODUCT SERVICE NOTE: Components marked with a have special characteristics important to safety. Before replacing any
of these components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. Don’t degrade the safety of the
receiver through improper servicing.
179
SYMBOL PART # DESCRIPTION
DP65
DP65G
SYMBOL PART # DESCRIPTION
DP65
DP65G
QL11 CF02771R TRS. KTA1270 0 0
QL12 CF02771R TRS. KTA1270 0 0
MISCELLANEOUS
QL13 CF02771R TRS. KTA1270 0 0 E001 GX00664 CLAMP FERRITE CORE K5B RC 26X3 0 0
QL14 CF02771R TRS. KTA1270 0 0 E002 GX00664 CLAMP FERRITE CORE K5B RC 26X3 0 0
QL15 CF02771R TRS. KTA1270 0 0 E003 GX00666 CLAMP FERRITE CORE K5C RC 16X2 0 0
QL16 CF02771R TRS. KTA1270 0 0 E004 GX00666 CLAMP FERRITE CORE K5C RC 16X2 0 0
QL17 CF02771R TRS. KTA1270 0 0 E005 GX00664 CLAMP FERRITE CORE K5B RC 26X3 0 0
E10B GX00516 MAG VM COIL 2PAL-4P 0 0
RESISTORS E10G GX00516 MAG VM COIL 2PAL-4P 0 0
RL10 0100129M RES.-CARBON FLM 1/8W 470K-JB 0 0 E10R GX00516 MAG VM COIL 2PAL-4P 0 0
RL11 0100129M RES.-CARBON FLM 1/8W 470K-JB 0 0 E12B BY01555 DY-V80-7SS(0.64)CYL 0 0
RL12 0100129M RES.-CARBON FLM 1/8W 470K-JB 0 0 E12B BY01664 DY-V80-7SS(0.65)LH 0 0
RL13 0100129M RES.-CARBON FLM 1/8W 470K-JB 0 0 E12B BY01794 DY-V80-7SS(0.65)LH 0 0
RL14 0100129M RES.-CARBON FLM 1/8W 470K-JB 0 0 E12G BY01555 DY-V80-7SS(0.64)CYL 0 0
RL15 0100129M RES.-CARBON FLM 1/8W 470K-JB 0 0 E12G BY01664 DY-V80-7SS(0.65)LH 0 0
RL16 0100129M RES.-CARBON FLM 1/8W 470K-JB 0 0 E12G BY01794 DY-V80-7SS(0.65)LH 0 0
RL17 0100129M RES.-CARBON FLM 1/8W 470K-JB 0 0 E12R BY01555 DY-V80-7SS(0.64)CYL 0 0
RL20 0100125M RES.-CARBON FLM 1/8W 330K-JB 0 0 E12R BY01664 DY-V80-7SS(0.65)LH 0 0
RL21 0700064M RES.-CARBON FLM 1/16W 56K-JB 0 0 E12R BY01794 DY-V80-7SS(0.65)LH 0 0
RL22 0100125M RES.-CARBON FLM 1/8W 330K-JB 0 0 # UE25831 D2XX-MAB 51 LENS CRT B.ASY(R) 0
RL23 0100127M RES.-CARBON FLM 1/8W 390K-JB 0 0 # UE25832 D2XX-MAB 51 LENS CRT B.ASY(G) 0
RL24 0100129M RES.-CARBON FLM 1/8W 470K-JB 0 0 # UE25833 D2XX-MAB 51 LENS CRT B.ASY(B) 0
RL25 0700066M RES.-CARBON FLM 1/16W 82K-JB 0 0 # UE25834 D2XX-MAB 57 LENS CRT B.ASY(R) 0
RL26 0100125M RES.-CARBON FLM 1/8W 330K-JB 0 0 # UE25835 D2XX-MAB 57 LENS CRT B.ASY(G) 0
RL27 0100123M RES.-CARBON FLM 1/8W 270K-JB 0 0 # UE25836 D2XX-MAB 57 LENS CRT B.ASY(B) 0
RL30 0700027M RES.-CARBON FLM 1/16W 100-JB 0 0 E2B EZ01862 COZ 2005 ANODE COVER 0 0
RL31 0700027M RES.-CARBON FLM 1/16W 100-JB 0 0 E2G EZ01862 COZ 2005 ANODE COVER 0 0
RL32 0700027M RES.-CARBON FLM 1/16W 100-JB 0 0 E2R EZ01862 COZ 2005 ANODE COVER 0 0
RL33 0700027M RES.-CARBON FLM 1/16W 100-JB 0 0 E3B 2958351 CONN. W/WIRE MINI 2J 0 0
RL34 0700027M RES.-CARBON FLM 1/16W 100-JB 0 0 E3G 2958351 CONN. W/WIRE MINI 2J 0 0
RL35 0700027M RES.-CARBON FLM 1/16W 100-JB 0 0 E3R 2958351 CONN. W/WIRE MINI 2J 0 0
RL36 0700027M RES.-CARBON FLM 1/16W 100-JB 0 0
RL37 0700027M RES.-CARBON FLM 1/16W 100-JB 0 0
CONNECTORS, JACKS
PDSE ED00389 PLUG 10P WITH LOCK 0 0
PS1 2959058 PINPOST 9P PH 0 0
PS2 2959059 PLUG PH PIN POST 10P 0 0
PS3 2959055 CONNECTOR-6P(PH) 0 0
FINAL ASS'Y
UQ36181 51F59 FINAL ASY 0
UQ36182 57F59 FINAL ASY 0
OTHER ASS'Y
UQ36183 65F59 FINAL ASY 0 #011 UE25971 51F59 CORE B.ASY 0
UQ36184 51F59A FINAL ASY 0 #012 UE25972 57F59 CORE B.ASY 0
UQ36185 57F59A FINAL ASY 0 #013 UE25973 65F59 CORE B.ASY 0
UQ36186 65F59A FINAL ASY 0 #014 UE25974 51F59A CORE B.ASY 0
#015 UE25975 57F59A CORE B.ASY 0
SPEAKERS #016 UE25976 65F59A CORE B.ASY 0
U402 GK01371 SP-12CM C120RB506-11 0 0 #021 QD53181 51F59 CABINET ASY 0 0
U402 GK01381 SP-16CM C160RB507-10 0 0 #022 QD53191 57F59 CABINET ASY 0 0
U404 GK01371 SP-12CM C120RB506-11 0 0 #023 QD53201 65F59 CABINET ASY 0 0
U404 GK01381 SP-16CM C160RB507-10 0 0 #031
#032
ACCESSORIES #033
E203 FQ00021 DRY BATTERY(R6P-AA) 0 0 #041 QG01842 51F59 REAR COVER ASY 0 0
E301 HL02291 REMOTE CONTROL CLU-4361S 0 0 #041 QG01852 57F59 REAR COVER ASY 0 0
N201 QR66562 DP65 INSTRUCTION BOOK REV.2 0 0
N202 QT47721 NATIONAL WARRANTY CARD 0
N203 QT44782 LCD/PTV CANADA WARRANTY CARD #2 0
N206 QT48191 DP65 EASY GRAPH.GUID 0 0
N212 QT48911 DP6X MAGIC FOCUS NOTICE 0 0
CONNECTORS, JACKS
EDS2 EF25469 10J 2.0MM PITCH PA CONNE. L=47 0 0
E999 EV00559 COD VM0284-212-C-LM 0 0
ECT 2973984 12J CONNECTOR L=750MM 0 0
EDC1 EF03228S CONNECTOR 0 0
EDF1 EF05942 4P CONNECTOR (L=680 N.C#2 3) 0 0
EFT1 EF23203 13P XA CONNECTOR 1100MM 0 0
EFT2 EF22132 CONNECTOR 11XA-XA1007-26/1347-24 1400 0 0
EL EF24322 5J XA-FASTON 1600MM #3 0 0
ER EF24332 4J XA-FASTON 1600MM #3 0 0
ESET EF23208 10P XA CONNECTOR 1500MM 0 0
ESF 2958152 CONN. W/WIRE 1J (L=550) W/CLIMP 0 0
!
!
!
!
!
!
!
!
DP65
