APPLICATION
Cutting various types of wood.
BATTERY REMOVAL/INSTALLATION
1. Battery removal
Hold the handle tightly and push the battery latches
to remove the battery (see Fig. 9, 10).
CAUTION
Never short-circuit the battery.
2. Battery installation
Insert the battery while observing its polarities (see
Fig. 10).
Fig. 9
Fig. 10
STANDARD ACCESSORIES
Standard accessories are subject to change without notice.
OPTIONAL ACCESSORIES (sold separately)
1. Battery (BSL1830, BSL1840, BSL1850)
2. Saw Blade
Use......Cutting various types of wood.
External Diam Hole Diam. No. of Teeth
125 mm 20 mm 24 pieces
3. Dust Collection Adaptor
The Dust Collection Adaptor collects sawdust when
the vacuum cleaner is attached to the power tool.
(How to attach the Dust Collection Adaptor)
Attach the Dust Collection Adaptor to the power
tool with the M4 screw (Fig. 8).
Connect the vacuum cleaner to the Dust Collection
Adaptor.
Fig. 8
Optional accessories are subject to charge without notice.
C18DBL
(NN)
1 Saw Blade (mounted on tool) ................................................................................ 1
2 Hex. bar wrench 4 mm............................................................................................ 1
3 Hex. bar wrench 2.5 mm......................................................................................... 1
C18DBL
(2LJRK)
1 Saw Blade (mounted on tool) ................................................................................ 1
2 Hex. bar wrench 4 mm............................................................................................ 1
3 Hex. bar wrench 2.5 mm......................................................................................... 1
4 Charger (UC18YFSL) .................................................................................................. 1
5 Battery (BSL1850)....................................................................................................... 2
6 Battery cover............................................................................................................... 1
7 Plastic case.................................................................................................................. 1
1
2
3
5
6
7
2
3
1
Dust collection
adapter
Screw
Push
4
Battery
Latch
Battery cover
Terminals
Ventilation holes
Latch
Handle
Battery
Pull out
Insert
