Item
No.
Part Name
1 BOLT (W/WASHER) M7×17.5
2 WASHER (B2)
3 TCT SAW BLADE 165MM-15.9
4 RING D15.9/I. D14.5
5 WASHER (A1)
6 SEAR LOCK FLAT HD. SCREW M3×12
7 BEARING COVER
8 BALL BEARING 6002VVCMPS2L
9 LOWER GUARD
10 BUSHING
11 SEAL LOCK FLAT HD. SCREW M5×12
12 BEARING HOLDER
13 GEAR
14 TAPPING SCREW (W/FLANGE) D5×50
15 FLAT HD. SCREW M5×20
16 CUSHION
17 HITACHI PLATE
18 SAW COVER
19 RETURN SPRING
20 LABEL (LC)
21 LIGHT COVER ASS’Y
22 NYLOCK BOLT (W/FLANGE) M4×12
23 INNER COVER (B)
24 BALL BEARING 609VVC2PS2L
25 LOCK LEVER
26 SPECIAL BOLT M5
27 INNER COVER (A) ASS’Y
28 MOTOR (B)
29 TAPPING SCREW D4×10
30 SOCKET
31 LIGHT
32 TERMINAL (D)
33 NAMEPLATE
34 HOUSING
35 CAUTION PLATE
36 CAUTION PLATE
37 SPRING
38 WING BOLT (A)
39 SUPER LOCK WASHER M6
40 BASE ASS’Y
41 KNOB BOLT
42 LOCK SPRING
43 SLOTTED HD. SET SCREW (SEAL LOCK) M6×6
44 BOLT ASS'Y (SQUARE) M2×22
45 WASHER M6
46 ROLL PIN D6×50
47 TAPPING SCREW (W/FLANGE) D4×16
48 HANDLE COVER
Item
No.
Part Name
49 RESISTOR (A)
50 CONNECTOR
51 SWITCH
52 SPRING (F)
53 KNOB
54 HOLDER SPRING
55 TERMINAL
56 TERMINAL PIECE
57 TERMINAL
58 BATTERY
501 CHARGER
502 BOX WRENCH
503 GUIDE
