4. Grounding the Equipment. (Fig. 2)
Prior to shipping, the equipment is subjected to a
rigid factory inspection to prevent electric shocks
during operation. Further, the equipment is provided
with a means of grounding as a safety precaution.
Wind the grounding wire round the power supply
cord not to contact with rotating portion.
5. Pull out the handle
The handle is pressed against the motor for shipping
purpose. Therefore, pull out the handle to the
position that offers the best operating comfort and
secure it in position with two cross-head screws.
6. Removing anticorrosive coating
Ascertain that anticorrosive coating on the base
surfaces is thoroughly removed with a cloth well-
moistened with gasoline.
CONFIRM BEFORE USE
CAUTION
Before plugging the power cord in a receptacle,
ascertain the following points:
1. Ascertain cut-off wheel condition
Ascertain that all cut-off wheels are in perfect
condition, and do not display scars or cracks.
2. Ascertain clamping of the cut-off wheel
Although they have been fully clamped at the factory
prior to delivery, re-clamp the clamping nuts securely
for safety. (See the item on Replacing the cut–off
Wheel).
SPECIFICATIONS
Item
Motor Output
2.2 KW 3.7 KW
Motor Type Three phase induction motor
Power source Three phase alternating current 50/60Hz
Voltage (V) 200 220 230 240 380 400 415 440
Full-load current
2.2KW 9.9/8.9 8.5/8.0 / / 4.9/4.6 4.8/4.4 4.8/
——
/4.3
(50/60Hz)
3.7KW
15.8/14.5
13/12.5 / / 8.0/
—
7.9/7.2 8.0/
——
/6.8
Cut-off Type Reinforced resinoid cut-off wheel
wheel Dimensions Outer diameter 405 × thickness 2.8 × arbor hole diameter 25.4 mm
Maximum working
3800 m/min
peripheral speed
No-load speed
2290/2730/min (50/60Hz) 2430/2900/min (50/60Hz)
No-load peripheral
2910/3470 m/min (50/60Hz)
speed
Distance from wheel lower
side to base top
170 mm
Dimensions of base top 583 x 370 mm
Maximum opening of vise
230 mm
Height of machine 965 mm
Weight 86 kg 96 kg
V-belt size Type 3V-375·············2
ACCESSORIES
APPLICATION
Cutting off the following materials:
䡬 Round bars
䡬 Pipes
䡬 Various types of shaped steel
䡬 Aluminum alloy (use a chip saw)
PRIOR TO OPERATION
Exercise care in the following procedures before
connecting the cord to power source.
1. Installation
This is a portable tool with wheels. Install it on a
level site and prevent it from sliding by securing
each wheel with a wedge or a similar peg.
2. Connecting the power cord to the machine body
Open the push-button switch and connect the power
cord to the connection terminal. (see Fig. 1)
Use a cabtyre cord with 2 mm
2
or more core wire
for the power cord.
3. Clamping the power cord
Use the nylon clip provided for the machine body
to clamp the power cord. (see Fig. 8)
Standard accessories
Cut-off wheel ················· 1
Spanner ·························· 1
Special accessories
(available on separate order)
Modification set for 3.7KW 51-P motor
