ITEM
NO.
PART NAME Q’TY
1 START LABEL 1
2 CLEANER COVER (C51) 1
3 SHUTTER PLATE 1
4 COVER SET BOLT 7
5 CYLINDER COVER (C51) 1
6 CLEANER KNOB 1
7 KNOB PACKING 1
8 CLEANER ELEMENT (B) 1
9 CLEANER ELEMENT (A) 1
10 NUT M6 3
11 BOLT WASHER M6 1
12 SPRING HOLDER 1
13
HEX. SOCKET HD. BOLT
(W/FLANGE) M6×20
1
14 ANTIVIBRATION SPRING 1
15 DAMPER SET BOLT 3
16 SEAL LOCK SCREW M4×10 18
17 SCAVENGING COVER (B) 1
18 COVER PACKING (C51) 2
19 EXHAUST PIPE (C51) 1
20 MUFFLER GAUZE (C51) 1
21
TAPPING SCREW
(W/FLANGE) D5×25
2
22 FRONT HANDLE 1
23
TAPPING SCREW
(W/FLANGE) D5×20
2
24
HEX. SOCKET HD. BOLT
M4×10
5
25 BOLT WASHER M4 5
26 MUFFLER PROTECTOR 1
27
MUFFLER PROTECTOR
PACKING
1
28 MACHINE SCREW M4×16 3
29 OIL PIPE (CS40) 1
30 OIL PUMP 1
31 CLIP 4
32
SEAL LOCK HEX. SOCKET
HD. BOLT M5×30
4
33 SEA LOCK SCREW M5×12 3
34 SPIKE 1
35
SEAL LOCK HEX. SOCKET
HD. BOLT M5×45
2
36 MUFFLER CAP 2
37
HEX. SOCKET HD. BOLT
M6×20
6
38
HEX. SOCKET HD. BOLT
M5×12
5
39 MUFFLER (C51) 1
40 MUFFLER PACKING (C51) 1
41 GROMMET 2
42 FUEL PIPE 2.5×4×90 1
43 PRIMING PUMP COMP. 1
44 DECOMP. 1
45 SPARK PLUG BPMR7A 1
46 INTAKE PACKING (C51) 1
47 INTAKE (C51) 1
48 CAB. INSULATOR RUBBER 1
49
CARBURETOR INSULATOR
(C51)
1
50 FUEL PIPE 1
51 CARBURETOR ASS'Y 1
52 SCREW 1
53 PUMP GASKET 1
54 PUMP DIAPHRAGM 1
55 INLET SCREEN 1
ITEM
NO.
PART NAME Q’TY
56 NEEDLE VALVE 1
57 VALVE SPRING 1
58
DIAPHRAGM PACKING-
METERING
1
59 METERING DIAPHRAGM 1
60
DIAPHRAGM COVER-
METERING
1
61 IDLE ADJUST SPRING 1
62 IDLE ADJUST SCREW 1
63 HINGE PIN SET SCREW 1
64 CONTROL LEVER 1
65 HINGE PIN 1
66 SET SCREW 1
67 FUEL PIPE 1
68 WASHER 5 5
69
HEX. SOCKET HD. BOLT
M5×45
2
70 CLEANER SUPPORT (C51) 1
71 FUEL PIPE 1
72 CYLINDER 1
73 SCAVENGING COVER (A) 1
74 CYLINDER PACKING (C51) 1
75 PISTON RING 2
76 PISTON (44) M 1
77 CIR CLIP 2
78 PISTON PIN COLLAR (C51) 2
79 ENGINE CASE (B) 1
80 OIL SEAL 2
81 BALL BEARING 6202C3 2
82 CRANK SHAFT 1
83
CRANK CASE PACKING
(C51)
1
84 PISTON PIN 1
85 NEEDLE BEARING (A) 1
86 ENGINE CASE (A) 1
87 REAR DAMPER (C51) 1
88 BRAKE HANDLE 1
89 CAUTION LABEL 1
90 BRAKE LEVER SPRING (B) 1
91 CHOKE ROD RUBBER 1
92 CHOKE BUTTON 1
93 OPERATIONAL PANEL 1
94 STOP SWITCH 1
111 NAME PLATE 1
112 FLANGE NUT M8 3
113 SIDE CASE SUB 1
114 CHAIN PULLER 1
115 SAW CHAIN 1
116 GUIDE PLATE (B) 1
117 BAR 1
118 OIL GROMMET (A) 1
119 FUEL PIPE 1
120 BOLT WASHER D5 1
121 OIL FILTER 1
122 OIL FILTER BODY 1
123 GUIDE PLATE (A) 1
124 DAMPER (C51) 2
125 CHAIN CATCHER 1
126 BRAKE LINK 1
127 BRAKE SPRING 1
128 BRAKE BAND 1
129 NEEDLE ROLLER D3 1
130 BRAKE LINK COVER 1
ITEM
NO.
PART NAME Q’TY
131 CLUTCH 1
132 CLUTCH WASHER (B) 1
133 CLUTCH HOUSING 1
134 NEEDLE BEARING 1
135 RIM SPROCKET 1
136 CLUTCH WASHER 1
137 OIL PUMP COVER (C51) 1
138 WORM 1
139 AIR VENT SPONGE 1
140 AIR VENT VALVE (B) 1
141
TAPPING SCREW
(W/FLANGE) D4×16
1
142 REAR HANDLE GRIP 1
143
THROTTLE LEVER
LOCKOUT
1
144 THROTTLE LEVER SPRING 1
145 NUMBER PLATE 1
146 REAR HANDLE 1
147 SPRING PIN 5×25 1
149 THROTTLE ROD 1
150 THROTTLE LEVER 1
151 AIR VALVE CAP 1
152 INNER CAP 1
153 GROMMET 1
154 PUMP FILTER BODY 1
155 FRONT DAMPER 1
156 SPRING HOLDER 2
157
FLANGED TAPPING SCREW
D6
2
158 ANTIVIBRATION SPRING 2
159 TANK MARK LABEL 1
160 TANK CAP PACKING 2
161 FUEL TANK CAP ASS'Y 2
162 BAND 1
163 PLUG CAP 1
164 CORD (A) 1
165 CORD (B) 1
166
METAL FITTING OF PLUG
CAP
1
167 IGNITION COIL 1
168
HEX. SOCKET HD. BOLT
(W/FLANGE) M4×18
2
169 MAGNETO ASS'Y 1
170 MAGNETO ROTOR 1
171 STARTER PAWL SPRING 2
172 WASHER 0.8 2
173 STARTER PAWL 2
174 SHIM 2
175 STEP BOLT 2
176 AIR DEFLECTOR 1
177 RECOIL STARTER 1
178 HITACHI LABEL 1
501 CHAIN COVER 1
502 COMBI BOX SPANNER 1
61
