1.11.7 Virtual PC-ART
6HQGLQJRUGHUVWRWKHXQLWVFDQEHGRQHE\HQDEOLQJWKH9LUWXDO3&$57RQORFDOFRPSXWHUFRQ¿JXUDWLRQ$IWHUVHOHFWLQJDXQLWWKH
remote controller will appear on the screen.
7KHUHPRWHFRQWUROOHULVGLYLGHGLQWZRSDUWVWKH¿UVWRQHLVWKHGLVSOD\]RQHWKDWVKRZV\RXWKHFXUUHQWYDOXHVRIWKHXQLWDQGWKH
second one is the buttons zone.
Display zones are described next:
1 Indicates the Run / Stop situation and if the unit has an alarm.
2 Shows the unit operation mode.
3 ,QGLFDWHVWKHSRVLWLRQRIWKHEDIÀHSODWH
4 Shows the fan speed.
5 Display central is enabled if some central value is activated.
6 Display the unit temperature.
Button zones are described next:
7 Changes the value of Run/Stop.
8 Show or hide the remote controller cover.
9 Set the temperature value.
10 Changes the unit mode. From left to right: Auto, Cool, Heat, Dry and Fan.
11 Set fan speed.
12 Set the position of louver.
13 Parameter lock. These parameters will be locked on the remote controller.
14 Update will send the current state of the remote controller to the unit. Cancel will restore previously setting.
15 ³6HWE\´RSWLRQVFRQ¿JXUHWKHFXUUHQWUHPRWHFRQWUROOHURUGHUWREHVHQWWRDVLQJOHXQLWDQRXWGRRUXQLWD]RQHD]RQHDQGLWV
sub zones or to all units.
