62
CP-A100 / ED-A100 / ED-A110 (A1DN)
Follow the procedure below to disassemble / assemble the Optics Unit.
Disassembling / Assembling the Optics Unit
(1)Disassembling/Assembling Dichroic optics unit
Remove 4 screws to detach the Dic hroic optics unit from bottom bracket.
Never remove the other screws.
Tighten 4 screws to attach the Dichr oic optics unit to bottom bracket.
Combine two
parts of dichroic unit to part of lens.
Meter screw
Tapping screw
parts of dichroic unit
part of lens
4.
To Next Page
