Hitachi FDV 20VB - Wiring Diagram for Models without Suppressor

--- 15 ---
(2) For Models without noise suppressor and choke coils
(Red)
(White)
(Black)
Wiring diagram
Switch
Cord
Connection of the carbon brush terminal and the stop piece
Stop Piece
Insert it with the convex side
faced upward.
Carbon brush terminal
(White)
(Black)(Brown)
(Blue)
Connection of internal wires to the stator
(viewed from the commutator side)
Housing (A) side
Housing (B) side
(White)
(Gray)
Connection of internal wires to the switch
For cord
(brown or black)
For cord
(blue or white)
(Red)
(Gray)
(Red)
(Black)
(Brown)
(Gray)
(Blue)
Forward/reverse
changeover section
(Blue or
white)
Main switch section
Cord
(Brown or
black)
Wiring diagram
(Brown)
(Black)
(Gray)
(Blue)
(Red)
(White)
